U-Scan is a sophisticated, high-tech device containing many unique components that contribute to its one-of-a-kind design. Below is a breakdown of its components to better help you understand the terminology and functions of the device.
Top/Front View
-
Cover - Protects the U-Scan reader's body and requires proper closure to ensure a watertight seal.
See our dedicated article on how to properly open and close the cover. -
Cartridge - A sophisticated container for urinalysis measurement tests.
See our dedicated article on how to install and replace a cartridge. - Main button - Controls the powering on and off of the device as well as the Bluetooth connectivity functions.
- USB-C port - An internal charging port that can be used as a backup option for charging with the Station.
- Closing pin - A small button that registers the closure of the cover.
-
Gasket - A grey rubber ring nestled in the inner screw threads of the Reader that keeps the watertight seal intact.
See our dedicated article for more info with humidity warnings. -
Status light - A dynamic LED that displays a variety of behaviors.
See our dedicated article to understand the various status light meanings.
Bottom/Back view
-
Toilet clip - A detachable clip that attaches to your toilet to suspend the U-Scan inside.
See our dedicated article on how to install the U-Scan in your toilet. - Anchor point - Where the toilet clip attaches to the U-Scan.
- Purge point - A small outlet that allows any fluid from the device to exit the device after every measurement, during its daily purging cycle, and during the deep cleaning process.
- Sample collection point - A small inlet with a fine mesh that collects your urine sample to be analyzed. A thermal sensor located at the collection point detects the presence of urine by a rise in temperature, allowing it to distinguish between urine and toilet water. The app will alert you if the collection point becomes obstructed. When the collection point is obstructed for any reason, it can lead to measurement failure.
